1. Pneumatic control the pressure of clutch:Pneumatic control the pressure of clutch, ink clutch fast and reliable, it can be adjusted up and down non- stop, fast and convenient.
2. High strength cast iron base:High strength cast iron base ensures high efficient printing.
3. Three-point suspension bearing:Rubber cylinder adopts three-point suspen-sion bearing, ensures the clutch pressure reliable and stable. Plate cylinder, press cylinder bearing all adopt tapered roller bearing, eliminate the beating due
4. Continuous alcohol lubrication system with auxiliary bridge roller:Continuous alcohol lubrication system with auxiliary bridge roller ensures printing products colorful and clear.
5. Shaftless driving:The machine adopts German Rexroth or Japan Yaskawa servo system, each unit has a separate servo motor, providing a guarantee for precise during high-speed running.
6. High machine options:As UV unit, cold stamping unit, film unit, rotary die cutting unit, stripping unit, cutting unit and delivery unit.
7. Overprinting system:Each unit is controlled by a separate motor; With static image monitoring system, horizontal and vertical overprinting can be achieved without stopping machine, greatly increase the printing quality and capacity.
8. Positioning system:Inputting printing length at the main control unit, each unit will reach to the preset position automatically, reduce the waste of time and materials.

Model	LZPS-350
Max. Printing Width(mm)	350
Max. Printing Length(mm)	350
Min. Printing Length(mm)	175
Max. Web Width(mm)	360
Printing speed	50-180times/minute (Max.63m/minute)
Printing Units	2-7 colors
Max. Unwinding Diameter(mm)	600
Max. Rewinding Diameter(mm)	600
Power	3 phase 380V
Total Power	25KW(5-color roll to roll), excluding UV
Machine Dimension(mm)	8700*2700*1600
Machine Weight(kgs)	10500(5-color roll to roll)
