1. High Strength ductile castings to ensure constant stabilization and die-cut precision.
2. Fast pneumatic clutch and chase locking.
3. Program control device and Man-machine interface.
4. World-wide well-known brand electric component makes the running of the machine smooth and reliable.
5. Frequency inverter to control main motor,steplessspeed increasing and decreasing.
6. Monitor in front to Show machine working speed,die-cut number and total running hours.ww


Model	LZ-1200T
Max. Sheet Feeding Size	1200x780mm
Min. Sheet Feeding Size	400x370mm
Max. Die-cutting Size	1190x770mm
Max. Machine Speed	6500S/H
Production Speed	4500~5500S/H
Sheet Thickness	Card Board:0.12-2.0mm;Orrugated Sheet≤4mm
Feeding Pile Height	1500mm
Delivery Pile Height	1220mm
Die-cutting Precision	≤±0.15mm
Die-cutting Pressure	350T
Overall Dimensions	6800X3900X2150mm
Total Power	17Kw
Total Weight	17T

Model	LZ-1060T
Max. Sheet Feeding Size	1060x760mm
Min. Sheet Feeding Size	400x370mm
Max. Die-cutting Size	1050x750mm
Max. Machine Speed	6500S/H
Production Speed	5200~6500S/H
Sheet Thickness	Card Board:0.12-2.0mm;Orrugated Sheet≤4mm
Feeding Pile Height	1500mm
Delivery Pile Height	1220mm
Die-cutting Precision	≤±0.10mm
Die-cutting Pressure	300T
Overall Dimensions	6800X3800X2200mm
Total Power	17kw
Total Weight	16T
