FEATURES
most of the materials in the packaging factory such as cardboard from 80gsm to 1200gsm.adhesive stickers,corrugated board less than 4mm,laminated  corrugated board,PET, PVC, PP and soon.At the same time,all the waste such as holes ,windows,oddly shaped corners can be stripped to lower the labor cost of cleaning and work intensity,improve the cleanliness of the packaging workshop and the customer recognitions about the order together with the stable production capacity and product quality.Counting and marking, die cutting plate preloading system and stripping unit preloading unit preloading unit are optional for customer (Operation out of  machine is more safe

MODEL Max. Paper Size	1050SP 1050*750mm	1060SP 1070*760mm	1188SP 1220*900mm	1260SP 1260*920mm
Min. Paper Size	400*350mm	400*350mm	430*360mm	430*360mm
Max. Die Cutting Size	1040*730mm	1060*750mm	1200-880mm	1240*900mm
Paper Range	80~1200g/m² Corrugated ≤4mm	80~1200g/m² Corrugated ≤4mm	80~1200g/m² Corrugated ≤4mm	80~1200g/m² Corrugated ≤4mm
Gripper Margin	8mm	8mm	8mm	8mm
Max. Die Cutting Speed	7500s/h	8000s/h	7000s/h	7000s/h
Die-cutting Accuracy	≤±0.075mm	≤±0.075mm	≤±0.075mm	≤±0.075mm
Max. Die Cutting Pressure	300T	300T	300T	300T
Total Power	18.5kW	18.5kW	23.5kW	23.5kW
Power	380V  3-phase 50Hz	380V  3-phase 50Hz	380V  3-phase 50Hz	380V  3-phase 50Hz
Total Weight	17T	17T	19T	20T
Overall Size	7016*4500*2400mm	8350*4250*2400mm	9150*4750*2500mm	9150*4750*2500mm
