Equipment Advantages:
Rapid machine adjustment: Servo positioning after 5 seconds of numerical input, automatically adjusting the machine according to size, greatly improving order change efficiency.
Millimeter accuracy: Motion-controlled servo positioning, with a precision of 0-1mm for sluice and shaped boxes, resulting in precise and attractive forming.
Stable conveying: A/B disc split-drive and variable frequency independent suction ensure smooth paper feeding, eliminating paper rubbing and errors.
Hot and cold dual coating: Aluminum thermal adhesive combined with stainless steel cold glue provides more uniform pressure application, wear-resistant, durable, and bonds more firmly.
Intelligent interaction: The digital display screen diagnoses faults in real time, with full-machine risk automatically locking to ensure efficient and safe human-machine operation.

Main Parameters:


Model	LZ-2300Z	LZ-2600Z	LZ-3500Z
Maximum paper feed size (per sheet)	1150*1150mm	1300*1150mm	1750*1150mm
Minimum paper feed size (per sheet)	450*320mm	450*320mm	450*320mm
Maximum height of the paper stack	400mm	400mm	400mm
Main motor power	1.5Kw	1.5Kw	1.5Kw
Total power	18Kw	18Kw	18Kw
External dimensions (Excluding conveyor belts and platform presses)	6300*3300*1800mm	6300*3600*1800mm	6300*4500*1800mm
