1. Imported front lay registration technique ensures accurate registration, with corrugated paper not advancing.
2. The automatic feeder for paper makes smooth and stable paper feeding.
3. Data can be set according to the paper size, which keeps the machine in good condition all the time.
4. The automatic corrugated paper feeding device uses suction belt, and the corrugated paper supporting device adopts extension type for different size of corrugated board.
5. The pressing roller adopts double sheet anti-impact structure to avoid the accidental damage.
6. The pre-loading device enables the next pile of paper to be stacked without stopping the production, thus reduce downtime.
7. The electric parts used are imported one, which makes the electric control system safe and stable.
8. Using PLC,servo motor, touch screen, convenient to operate.
9. Using automatic gluing system, improve the level of automation.
10. Using fuequency conrerter, realizes stepless speed change.

Model	LZ-1300
Max. paper size	1300×1200mm
Min. paper size	360×360mm
Paper thickness	200-450g/㎡
Appropriate paper	A、B、C、D、E、F Corrugated board, thickness≤8mm
Laminating precision	2-5mm adjustable（front lay precision±1.5mm）
Max. speed	120m/min
Production efficiency	2000—6000(sheets/h)
Total power	12.5kw
Overall dimension	11500×2150×2300mm
Weight	5800kg

Model	LZ-1450
Max. paper size	1450×1200mm
Min. paper size	360×360mm
Paper thickness	200-450g/㎡
Appropriate paper	A、B、C、D、E、F Corrugated board,thickness≤8mm
Laminating precision	2—5mm adjustable（front lay precision±1.5mm）
Max .speed	120m/min
Production efficiency	2000-6000(sheets/h)
Total power	12.5kw
Overall dimension	11500×2300×2300mm
Weight	6500kg

Model	LZ-1600
Max. paper size	1600×1450mm
Min. paper size	360×360mm
Paper thickness	200-450g/㎡
Appropriate paper	A、B、C、D、E、F Corrugated board, thickness≤8mm
Laminating precision	2—5mm adjustable（front lay precision±1.5mm）
Max. speed	120m/min
Production efficiency	2000—6000(sheets/h)
Total power	17.5kw
Overall dimension	12500×2500×2300mm
Weight	7000kg
