1. High precision
Uses German advanced front lay registration technology, accurate and stable and the corrugated paper never advance while paper can be adjusted within 0-25mm for advancing.
2. High efficiency
Paper can be fed continuously to avoid lowering production efficiency caused by the large distance between two sheets.
3. Easy operation
Scientific and reasonable design concept enables the machine to be operated by operators without skillfulness. The card to corrugated board lamination is done by the machine itself. The paper lifting device makes it easy for paper feeding. It simplifies several traditionally feeding actions as one, which reduces labor intensity greatly. Equipped with paper lifting device, the semiautomatic flute laminator is just one step away from the automatic one.
4. Application range
Used for card to A,B,C,D,F flute corrugated paper lamination.
5. Low fault
Scientific and reasonable mechanical structure cooperating with imported high quality electric automatic control system ensures the machine run at low fault. It effects a permanent cure for user’s troubles back at home.

Model	LZ-D1300
Max. paper size	1300×1100mm
Min. paper size	360×360mm
Lamindin precision	2mm
Speed	0-100m/min
Total Power	8.5kw
Weight	3.8T
Overall dimension	11000×2000×2300mm

Model	LZ-D1450
Max. paper size	1450×1200mm
Min.paper size	360×360mm
Lamindin precision	2mm
Speed	0-100m/min
Total Power	8.5kw
Weight	4.5T
Overall dimension	11000×2150×2300mm

Model	LZ-D1600
Max. paper size	1600×1200mm
Min.paper size	360×360mm
Lamindin precision	2mm
Speed	0-100m/min
Total Power	10kw
Weight	5T
Overall dimension	12000×2300×2300mm
