High precision uses German advanced front lay registration technology, accurate and stable and the corrugated paper never advance while paper can be adjusted within 0-25mm for advancing. High efficiency Simple and easy feeding way enables easy and free operation for paper and corrugated board, which enhances production efficiency and reduces labor intensity.Easy operation. Large serviceable range Used for card to A,B,C,D,F flute corrugated paper lamination. Low mal-function Scientific and reasonable mechanical structure cooperating with imported high quality electric automatic control system ensures the machine run at low mal-function. It effects a permanent cure for user’s troubles back at home.

Model	LZ-1100
Max. paper size	1100×1100mm
Min. paper size	360×360mm
Laminating precision	2-5mm adjustable（front lay precision±1.5mm）
Speed	0-65m/min
Total Power	5.3kw
Weight	3.0T
Overall dimension	8500×1600×1700mm

Model	LZ-1300
Max. paper size	1300×1100mm
Min. paper size	360×360mm
Laminating precision	2-5mm adjustable（front lay precision±1.5mm）
Speed	0-65m/min
Total Power	5.3kw
Weight	3.3T
Overall dimension	8500×1800×1700mm

Model	LZ-1450
Max. paper size	1450×1200mm
Min. paper size	360×360mm
Laminating precision	2-5mm adjustable（front lay precision±1.5mm）
Speed	0-65m/min
Total Power	6kw
Weight	4.0T
Overall dimension	9500×2000×2000mm
